Zhonghuan backpack oxy-gasoline cutting "rescue kit"


ZHONGHUAN Backpack Oxy-Gasoline Cutting Torch-"Rescue Kit"
A ZH-C30T-DL handle cutting torch with 3 cutting nozzle, cutting thick range 3-40mm(approx. 1/8-1 1/2 inches) steel. The max cutting thick is 50mm(2 inches).
A 0.4 gallon stainless gasoline fuel tank filled with explosion-proof material.
A Carbon fiber oxygen tank ( 6.8 liters, more than 20 minutes cutting)
A oxygen regulator, gasoline and oxygen hoses;
A PVC Ergonomic Design Back Rack
A tool box with related tools and spare parts
Table : 30 cutting nozzles performance parameters
ZHONGHUAN brand QGB30 type Package Rescue oxy-gasoline cutting outfit Standard is the perfect equipment for fire department, search and rescue, military use and other rescue applications. It is light and portable, safe and easy to use.
The brief introduction of QGB-30 type fire-fighting emergency petrol cutter bar
At the shocking and extremely horrible scene of conflagration, the iron railings seals up the doors and windows for survival. The isolated roadblocks prevent the fire trucks from entering the passages to the scene of fire, and the conflagration is swallowing the fives. This kind of accident happens sometime at home. At present, the main braking and discharging tools equipping the fire brigade at home and abroad are: hydraulic pincers, teeth-less saw etc. However there are great limitations for their applications at the scene. They can be effective for the steel guardrails made from circular steel or square steel, but they are very difficult for breaking and discharging the subjects in the residence park, such as roadblocks, separation doors for fight fighting made from circular steel and square steel, and the circular steel and square steel with stress, or it is completely impossible to finish the breaking and discharging work. Thus it brings serious delay to the time for fire -fighting and rushing for deal with emergency. The reality at the scene of conflagration tells us that time means money and time is life. Fire- fighting and rushing to deal with the emergency is the fight to seize every minute and second. How time is important and precious. Thus Harbin Fire-fighting Branch and Harbin Zhonghuanke energy saving Equipment Co. Ltd. Have researched and developed portable fire-fighting and emergency dealing- oriented gasoline cutter, which can supplement effectively the shortcomings and insufficiencies found in teeth-less saw and hydraulic breaking pincers, and it can operate with water. In addition, it is tested and qualified by the State Fire fighting Equipment Monitoring and Inspection Center, and is listed as the state priority new product by the five ministries and administrations of the State Ministry of Science and Technology, State Ministry of Foreign Trade and Economic Cooperation, State Administration of Taxation, State Administration of Quality Monitoring, Inspection and Quarantine, and the State Administration of Environment Protection.
The portable fire- fighting and emergency-oriented gasoline cutter can cut rapidly obstacles of steel structure, theft-protection window guard guardrail, iron railings and iron pile preventing the vehicle from passing with 30mm. The product is characteristic of light- weight, being both portable and bearable, great cutting power, rapid speed, all-dimensional cutting, operable with water. The product is equipped with carbon fiber oxygen bottle with a capacity of 6.8-9 liters, with the effective working time 20 minutes, not more than 3 minutes for cutting the iron door for theft prevention under normal conditions; only 7 seconds are needed for cutting square steel 20mm 20mm; 30 seconds are needed for cutting the iron pipe with a diameter up to 20mm. Under the same conditions, in comparison with the other braking and discharging tools, the efficiency is double raised in comparison with the teeth-less saw, 4 times increased than the hydraulic breaking pincers. How precious every minute and second is in the scene of conflagration. The configuration of the product is as follows:
The equipment is mainly equipped with one carbon fiber oxygen bottle, one gasoline storage tank, one cutting tool, one bearing rack, and three cutting torches.
The main performances and characteristics of the equipment:
1. Light weight, small volume, total weight of the equipment up to 13kg, contour dimension: height 700 160mm.
2. Comprehensive function. The equipment can cut the various obstacles of low carbon steel and low alloy steel, such as the steel plate that less than 30mm, iron railings, iron theft-prevention doors and windows, steel roadblocks, iron-sheet roofs and steel structure etc. And it is suitable to all dimension cuttings and can be operable with water.
3. Rapid speed in cutting, quicker than the other breaking and discharging tools (such as teeth-less saws and hydraulic breaking pincers etc.)
4. Simple operation. The equipment can be operable in a simple, convenient way and can be easily mastered. Any fighter given slight training can be adaptable to operation in fight.
5. Good economic performance. The product uses the cheap gasoline as the fuel, and it is easy to collected the gasoline.
6. Good safety performance. The oxygen bottle wholly wound by carbon fiber for the equipment will not product fragments to make damage to the person even if it explodes. The pressure stable gasoline storage tank is fully filled with the material for explosion prevention and explosion suppression which reaches the world advanced level. And it is equipped with the safe pressure relief device, and the explosion probability can be controlled to zero.
Since reform and opening, our economy rapidly develops. In order to ensure the achievements of economic development, it is necessary to equip the fire- fighting troops with the science and technology achievements based on high science and technology, and to increase their ability in the fight to eliminate fire.
On September 24, 2004, The General Administration for Fire-fighting of Heilongjiang Province convened the meeting for demonstration of and competition in skills for the province-wide fire-fighting troops, to inspect the use result for the troops to master the high science and technology equipment. In the competition, Harbin Fire-fighting branch and the Heihe Branch used the Zhonghuan Brand portable gasoline cutter in discharging the theft-prevention windows and doors. And they won the good achievements ranking the first and the second respectively. The time used is from double to four times quicker than the teeth-less saws and the other equipment in breaking and discharging. They showed their advantages of good breaking and discharging performances and convenient portability, especially they can operate with water. Moreover, they have the extremely big safety coefficient. And they are the high science and technology equipment of new type for fire fighting in rushing to deal with emergency and breaking and discharging.
The portable fire- fighting and emergency-oriented gasoline cutter VCD/RM
Zhong Huan Petrol cutter VCD/RM
Harbin Zhonghuanke Environmental Protection Equipments Co. Ltd. gathered the high-grade experts in the area, it is the first enterprise which specialized in the research and development of petrol cutter bar. This enterprise has been the leader of the core technology in the petrol cutting area for these years.
The petrol cutting is the great item which can save the energy. It can save more than 80% energy compared with acetylene. There is no flash-back and explosion when using. It is safe and has created the new history of flame cutting!
Zhonghuan has the special patent that is leaded in the world:
National leading: the special stream into drawing system ( It doesn t need to be pressured, and can be used smoothly at the place higher than 60m,and it can do Omni bearing cutting of 360 . This is incomparable for the other product of the same kind!)
National leading: the special warm-pressing oil-control system (adopt the separating technology of oil and oxygen. It is safe when using. The oil-control is accurate, and the oil synchronizes with the oxygen. It is rapid to ignite, and is easy to operate!)
National leading: the special high-strength durable structural design (the cutting torch is not afraid of the being pressed and tamped. It can be used normally even after being deformed. We can also design and produce all kinds of deformed cutting torch and super thick cutting torch.)
Zhonghuan petrol cutter outfit series of products:
It has got the silver award of the national invention award.
All products are supervised by Harbin welding institute.
It is the only product that has been recommended by China welding institute in this area.
It has been listed as the new national major item by the five main departments of china.
The implementing standard: according with the enterprise standard
This standard is higher than the national standard
Hand-hold petrol cutter bar series of product
Semi-automatic petrol cutter bar series of product
petrol cutter bar series of product
