Rgb 5M 5050 flash led strip light dream color 94 change
This is a 500cm 5050 SMD Dream Color Decoration LED Light Strip
Come with 94 different changing types
Great for holiday, disco, party, home, garden and shops decoration etc.
Number Of LED/Per Meter: 30pcs
This controller is design for led production which uses ZJ168 as driver, it is very useful for light box advertisement, stage light, house decorating, and so on
With digital tube, left two reveal the mode, right two reveal the speed
ON/OFF button, it can open or close led anytime, when led is on the station of closing, The digital tube will display P*** , *** is the value of current setting.
Play/pause button, pressing this button to pause, you can see the static affection of led.
Adding button, to add the IC NUMBER, the most number is 500 (1500 group of RGB)
Reducing button, to reduce the IC NUMBER, the least number is 3 (9 group of RGB)
Program choosing button, up direction there are 94 programs in all.
Program choosing button, down direction.
Speed slow button, there are 99 step in all, the most number is 99. Speed quick button, the least number is 1.
ON/OFF: ON/OFF button, it can open or close led anytime.
MODE: Play/pause button, pressing this button to pause, you can see the static affection of led.
S+: Speed quick button, the least number is 1
S-: Speed slow button, there are 100 step in all, the most number is 100
B+: Program choosing button, up direction there are 94 programs in all.
B-: Program choosing button, down direction.
Supply voltage of this product is DC12V never connect to other high voltage.
Never connect two wires directly in case of short circuit.
Lead wire should be connected correctly according to colors that connecting diagram.
Warranty of this product is one year, but exclude the artificial situation of damaged.
1 x 5M Dream Color Waterproof LED Strip
1 x Power Supply(Input: AC 100-240V 50/60Hz, Output: 12V 3A )
