10X-80X stereo microscope + 2MP camera 4 vista window 7
Trinocular 10x~80x Zoom Stereo Microscope
Compatible with Windows 2000/XP/Vista/7 (32bit and 64bit)
* Zoom lenses 10x~80x, crystal clear within any range
* 45 inclined 360 rotatable trinocular head
* Variable intensity incident and transmitted lights
* Both ocular tubes have diopter adjustment
* Locked-in eyepieces avoid lens damage
* Easy to mount ring lights (sold separately)
* 2.0MP high resolution color digital camera can capture live and still images
* High speed USB 2.0 connection with computers
* Advanced software applications included
* Compatible with Windows 2000/XP/Vista32/Vista64/Windows 7 (see compatibility table below)
* Head: 45 Inclined 360 rotatable Trinocular.
* Eyepieces: super wide field SWF10X & WF20X
* Total magnification: 10x~80x
* Both ocular tubes have diopter adjustment 5dp
* Resolution: true color 1600x1200 pixels
* Interface: USB 2.0 (480Mb/sec)
* Pixel size: 2.8 um x 2.8 um
* USB cord length: 6 feet (183cm)
* Working distance: 3-3/8" (85mm)
* Incident (upper) illuminator: 12V/10W halogen, variable inclination, variable intensity
* Transmitted (lower) illuminator: 12V/10W halogen, variable intensity
* Standard dimension: 9-1/2" x 9-1/2" x 16-1/2" (24cmx24cmx42cm)
Please check the chart below for computer operating system compatibility
* Trinocular stereo microscope with vertical extend tube
* A pair of SWF10X eyepieces
* 0.45X medium adapter (mount on the USB camera)
* 1 CD including Driver for Windows 2000/XP/Vista32/64/Windows 7, and processing software applications
* Eyetube conversion adapter with rubber ring for stereo microscopes
* Digital camera adapters (Nikon, Olympus, Canon, Ricoh)
* Spare halogen bulb 12V/10W
* Spare halogen bulb 12V/10W with reflector
Click the button above to see compatible product list for XG432C20C
