13.5V dc 29.6A 400W switching power supply s-400-13.5
* AC input range selectable by switch
* Protections: Short circuit/ Overload
* Cooling by free air convection
* Low cost, high reliability
* AC input voltage range ......... 90-132VAC / 180-264VAC selectable by switch
* AC inrush current ................. Cold start, 25A at 115VAC, 50A at 230VAC
* DC adjustment range ............ 10% rated output voltage
* Overload protection .............. 105%-135% hiccup mode, auto-recovery
* Setup, rise, hold up time ....... 200ms, 50ms, 20ms at full load and 230VAC
* Withstand voltage ................. I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC, 1 minute
* Working temperature ............ -10~60oC (refer to output derating curve)
* Safety standards .................. Design refer to UL1950
* EMC standards .................... Design refer to EN 55022:1998, EN 61000-3-21-3 EN55024:1998 (EN 61000-4-21-31-41-51-61-11)
* Connection .......................... 9P/ 9.5mm pitch terminal block
Please ignore S-240-24 in the image. The real product is S-400-12
Our email address is ****@sina.com. If you have any questions, please send email to us.
