Mmcx plug mount pcb connector straight attractive
MMCX Plug mount PCB connector straight attractive
Manufacturer's Part #: RF-0664
Temp.range....................-55 +155 (centigrade)
Impedanec.....................50
Frequency Range...............DC 6GHz
Working Voltage...............170V max
Withstand Voltage.............500V rms
Center Contact................ 5m
Outer Contact................. 2.5m
Insulation resistance......... 1000 m
VSWR Straight................. 1.15
Right angle................... 1.25
Durability(mating)............ 500 (cycles)
