Agilent 37719B /013/014/106/200/601/602 com analyzer
Agilent 37719B /013/014/106/200/601/602 Com Analyzer
The OmniBER 719 (37719B) communications performance analyzer is a single-box portable multi-rate BER and jitter tester up to 622 Mb/s (OC-12) for development, qualification and manufacture of SONET, ATM and POS network equipment, sub-assemblies, line cards and devices.
* POS test capability to 622 Mb/s
* ATM test capability to 622 Mb/s
* OC-12, OC-12c, OC-3c, OC-3, OC-1, STS-3, STS-3c, STS-1 testing
* Upgradeable to OC-48 (2.5 Gb/s)
* Protection switching time measurement
* Concatenated payloads at all synchronous rates up to 622 Mb/s
* Comprehensive thru-mode operation for SONET ring turn-up
* Full overhead access plus overhead sequence generation and capture
* Full pointer sequence generation to Telcordia GR.253
* Jitter generation and measurement at all rates to 622 Mb/s
* Jitter testing to Telcordia GR-253, ITU-T G.825, G.958, O.171 and O.172
* Remote Control by GPIB, LAN and RS-232
"X01" contains the following options:
* Option 013 - T Carrier Testing
* Option 014 - E1 into DS3 Mapping
* Option 106 - 1310/1550 nm Optical Interface and BER
* Option 200 - Jitter Generation and Measurement
* Option 601 - LAN+RS232 + HPIB Remote Control
* Option 602 - Graphics Printer
