36" Tbl 43" Swg King 36 VERTICAL BORING MILL, Turret &
36" Table 43" Swing King 36 VERTICAL BORING MILL, Turret & SideHead,FacePlate, ScanoMatic Tracer,
TABLE DIAMETER .............................. 36"
MAXIMUM SWING WITHOUT SIDE HEAD ............. 43"
MAXIMUM SWING WITH SIDE HEAD ................ 40"
MAX HEIGHT UNDER TURRET TOOL ................ 31-1/2"
VERTICAL TRAVEL OF TURRET SLIDE ............. 30"
SWIVEL OF TURRET SLIDE ...................... +/- 30 DEGREES
STROKE OF SIDE HEAD RAM ..................... 16"
VERTICAL TRAVEL OF SIDE HEAD ................ 23"
TOP OF TABLE TO BOTTOM OF SIDE HEAD TOOL .... 19"MAX
TABLE SPEEDS (16) ........................... 4.65 - 140 RPM
FEED RANGE (12) ............................. .010 - .5 IPR
FINE FEED RANGE (12) ........................ .003 - .125 IPR
APPROXIMATE WEIGHT .......................... 27,500 LBS
PENTAGON SWIVELING TURRET HEAD
SCANOMATIC TRACER ON SIDE HEAD
TIMKEN ROLLER BEARINGS ON TABLE
30 HORSEPOWER MAIN DRIVE MOTOR
