Tol-o-matic axiom plus PV30 servo controller/drive
Brand New Item, Never Installed with software.
The Tolomatic AxiomPlus features a Motion Controller, Brushless Servo Drive, and PLC all in one package. This sequential controller offers the savings of money and time spent on separate wiring of each component. The integrated vector drive technology is the same as the DV series Axiom Drives.
The PLC features real time scans of 2-4 milliseconds, ladder logic programmed in a Windows based point and click editor, timers, counters, output coils, and more. All comments and labels are stored with the program when downloading to the AxiomPlus. Motion control includes that of 1 or 1.5 axis. A full command structure consists of incremental/velocity moves, branching to labels, repeat loops, time delays, wait on conditions, and more. Operation is 115/208-230 VAC input, single or 3-phase.
Other features include 15 optically isolated inputs, 8 optically isolated outputs, 3A brake relay, short circuit-over current and over voltage protection.
PV30 - 30A Peak, 15A Cont, 4.2 kW Brushless Drive
