Napco gem-recv-XP8 wireless receiver for P800 & xp pnl.
(1) NAPCO GEMINI GEM-RECV-XP8 Wireless Receiver for XP-Series and GEM-P800 Control PanelsNew in Box Warehouse SurplusNote: 100% guaranteed that the receivers are in perfect condition and not used or installed.
* GEM-RECV-XP8 receiver is the hardwired interface to Napco's Wireless-Ready XP-Series and GEM-P800 Control Panels.
* The wireless system comprises an XP-400, XP-600 or GEM-P800 panel, at least one GEM-RECV-XP8 receiver and one or more companion transmitters.
* The transmitters may be wireless smoke detectors, space protection devices, window/door sensors, or other devices that report zone status and supervision information to the receiver without the use of wires.
* The GEM-RECV-XP8 will accommodate up to 8 wireless transmitters, 4 GEM-SMK wireless smoke detectors, and 4 GEM-KEYF Key-Fob transmitters.
* The receiver is connected to the keypad 3-wire bus.
* The receiver monitors each transmitter, updating transmitter status as reports are received, and conveys this information to the control panel.
* Also monitored is the elapsed time since the last report from each transmitter.
* If no report is received within a programmed time, the panel will issue a Supervisory Failure system trouble.
Any of the following Napco wireless transmitters may be used with the GEM- RECV-XP8 receiver.
* GEM-TRANS2 Window/Door Sensor
* GEM-TRANS4 Window/Door Sensor
* GEM-PIR Dual-element passive infrared sensor
* GEM-DT Dual-technology PIR/microwave sensor
* GEM-KEYF Key Fob Transmitter
* Operating Temperature: 0 degree C to 49 degree C (32 degree F to 120 degree F)
* Storage Temperature: -20 degree C to +85 degree C
* Power Requirements: 12Vdc, 60mA (supplied by panel).
* Dimensions: 6" x 3 5/8" x 1 1/2" (HxWxD, less mounting tabs)
* Please contact us of any problem with the item you received within 7 days of your receiving it.
* You have 30 days to return the defective item. .
* Return is for item that is DOA or if not meet the specifications listed above.
* We are not in any way associated with Napco Gemini or any of their affiliated company.
