Alc-B5655VIR high res 560 tvl, long range night vision
Super High Resolution, Long Range Night Vision, 5-50mm Bullet Camera
Alcatraz ALC-B5655VIR Super High Resolution with 560TVL, Long Range Night Vision, 5-50mm Bullet Camera
Bulk pricing available for dealers/resellers
The Alcatraz ALC-B5655VIR is a high-end varifocal bullet camera with an incredibly sharp 560 TVL. It features concealed bracket cable management to protect your cord from intruders. This camera is completely waterproof, and can be used indoors or outdoors. It comes with a 5-50mm externally adjustable lens which allows installers to maximize the view angle of the camera. 15 non-glare super LED provide up to 250' of crisp night vision reach.
Another great feature of the ALC-B5655VIR is a 3-axis rotation bracket which allows mounting in any surface (ceiling, wall, or surface top).The ALC-B5655VIR also features dual voltage 12VDC and 24VAC to give you flexibility on your installtion.
NTSC=768(H) * 494(V) / PAL=752(H) * 582(V)
CDS OFF 0.002Lux / CDS ON 0.00006Lux
Photoconductive Cells 10 Lux Resistance 5~10k ohm
NTSC=1/60 - 1/100,000 Sec / PAL=1/50 - 1/100,000 Sec
DC Auto iris Varifocal Lens (5mm-50mm)
-10 Deg -+ 50 Deg C RH 95% Max.
-20 Deg -+ 60 Deg C RH 95% Max.
100mm(W) * 134mm(H) * 290mm(D)
