350W 36V 9.7A single output switching power supply
- CNC Router Engraving Machine
- CNC Stepper Motor Drive Board
350W 36V 9.7A Single output Switching Power Supply
AC input voltage range ......... 90~132VAC / 180~264VAC selectable by switchAC inrush current ................. Cold start, 25A at 115VAC, 50A at 230VACDC adjustment range ............ 10% rated output voltageOverload protection .............. 105%~135% hiccup mode, auto-recoverySetup, rise, hold up time ....... 200ms, 50ms, 20ms at full load and 230VACWithstand voltage ................. I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC, 1 minuteWorking temperature ............ -10~60OC (refer to output derating curve)Safety standards .................. Design refer to UL1950EMC standards .................... Design refer to FCC part 15 JConnection .......................... 9P/ 9.5mm pitch terminal blockPacking ............................... 1.07kg ; 12pcs / 13.5kg / 0.92CUFT
