6PCS: hubbell 4P5W 30A locking conn. for flat cable
HBL2813FC Twist-Lock Connector Body
4P5W, 30A 3PH 120/208V AC, L21-30R,
#10-32 Brass (white finish on neutral screw when used) Multi-drive
#10-32 Brass (green finish) Multi-drive
Steel, zinc plated Multi-drive
Permanently ink marked on product
Certified for current interrupting at full rated current
Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75.
Flat portable service cords of dimensions commensurate with the device rating as defined in UL Standard 62, CSA C22.2 No. 49.
Terminals identified in accordance with UL 498 (X, Y, Z, White, Green)
HB or better per UL 94 or CSA 22.2 No. 0.6
Maximum Continuous 75 C Minimum -40 C (w/o impact)
This listing is for six (6) 30A twistlock connectors.
