Hp 54815A infiniium oscilloscope 500 mhz , 1 gs a/s
HP 54815A INFINIUM OSCILLOSCOPE -
Agilent / HP 54815A - Oscilloscope 500MHz 1GSa/s 4 Channels
he Agilent 54815A is an Infiniium Oscolliscope combine ease of use with the right specifications and a broad feature set to get measurement job done faster.
The 54815A oscilloscope gives the simple, uncluttered front panel of an analog scope for accessing basic functions. Dedicated scale and position knobs for each channel provide intuitive operation. Trigger LEDs show trigger status at a glance. To speed up measurements, the QuickMeas key gives instant access to any four measurements.
The 54815A scope employs a graphical user interface based on Windows 98. Windows familiar interface avoids spending a lot of time learning and relearning the scope.
The 54815A scope gives the tools needed to document and share the results of the work. It takes just a few mouse clicks to save waveforms and screen bitmaps to hard drive, floppy, or, when networked, to a drive on your network.
LAN connectivity also printing results to networked printers, and makes it simple to share waveforms and data with others.
With bandwidths to 1.5 GHz and sample rates to 8 GSa/s, Infiniium oscilloscope can view fastest signals. Powerful triggering and analysis makes it easy to capture and analyze your waveforms.
Display and math features like colorgraded persistence and histograms let easily view and isolate signal problems faster.
The 500 MHz bandwidth of 54815A provides exceptional performance and capability for general purpose lab measurements. Select a sample rate of 1 or 2 GSa/s based on the need for single shot measurement accuracy
The 54815A oscilloscope provides a wide variety of math functions, including Fast Fourier Transforms (FFTs) and histograms. The graphical user interface gives a new, easier way to zoom.
The built-in information system puts measurement assistance at your fingertips in seven different languages (English, French, German, Japanese, Korean, Traditional Chinese and Simplified Chinese).
The VoiceControl option of the 54815A allows the user to speak natural English language commands through the supplied collar-mounted microphone, allowing hands-free operation of the front panel.
Agilent 54815A Infiniium scope includes powerful Violation Triggering technology, making it easier for you to capture and view your toughest signals.
In addition to standard capabilities such as edge, glitch, logic, state, and video trigger, Violation Triggering adds the ability to trigger on rise time, fall time, setup and hold time, and runt pulses.
* Built-in information system
* Simple, analog-like front panel with Windows GUI
* USB Test option with embedded MatLab
* Time correlation between 16700 logic analyzer and scope
* Communications mask test kit option
* Voice Control option for hands free operation
* Web-enabled remote control from any web browser
* LAN printer and file sharing
* Eye diagrams and mask testing
Maximum Effective Sample Rate Equivalent Time
Random repetitive sampling (higher time resolution at faster sweep speeds)
Captures and displays narrow pulses or glitches 1 ns or wider at sample rates of 250 MSa/s or less
1 MO 1% (~8 pF), or 50 O 1%
dc, ac (7 Hz, available in 1 MO only)
250 V (dc + ac) [ac<10 kHz], CAT I
Hardware Bandwidth Limit (-3 dB)
Channel-to-Channel Isolation (with channels at equal sensitivity)
dc to 50 MHz: 50 dB 50 MHz to 500 MHz: 40 dB
Full Resolution Channel Scales
All volts/division settings = 7 mV/div
Horizontal Position Range (pre-trigger)
0 to -1 s or one full screen width, whichever is larger
Horizontal Position Range (post-trigger)
0 to 1 s or one full screen width, whichever is larger
1 ps/div to current main time base setting
Within main time base acquisition record
