Miyano model 34C2 cnc lathe turning center w/fanuc 0T
Miyano Model BND-34C2 CNC Turning Center With Fanuc 0T Control - NEW 1994 - IN EXCEPTIONAL CONDITION !! BAR FEED !
referencing Miyano Model BNC-34C2 CNC Turning Center
Miyano Model BND-34C2 CNC Turning Center With Fanuc 0T Control
Technical Specifications: * Item #7803-440
* Machine Serial Number: 30310C
* Operating Voltage: 220, 3 Phase
* Bar Capacity: 1.25" max 1/2" min
* Collet Chuck: Hardinge 22
* Inner dia of draw tube: 1.417"
* Chucking System: Hyd Rotary Cylinder
* Spindle Speeds: 170-5000 rpm
* Main Turret Axes Controlled: 2
X/Z travels: 4" / 9.25" * Rapid Rate: 394 ipm
* Machine dimensions: 59" x 96"
EQUIPPED WITH: * Fanuc Series O-T CNC Control
COMPLETE SET OF OPERATION AND TECHNICAL MANUALS-MACHINE AND CONTROL Machine Purchased NEW from Miyano North America by the AT Cross Company (Internationally known writing instrument manufacturer) in Rhode Island * CRT Monitor
* Grindley Hydrodynamic Bar Feed Unit S/N0732
Contact DAVID GOLD at 401.724.3200 EXT 111 during normal business hours (EST) OR Cell# (***)-864-4446 OR Email ****@goldmachinery.com referencing Miyano Model BND-34C2 CNC LATHE /Turning Center.
