Common anode rgb waterproof amplify for rgb(5050) strip
Common Anode RGB Waterproof Amplify for RGB(5050) Strip
RGB waterproof-Amplifier adjust to all the voltage-controlled LED (common anode) controller of our store, it has waterproof function, RGB could accept PWM (Pulse Width Module), Each one RGB amplifier can be added, the connecting number of LED will up to more than twice, countless RGB amplifiers could be connected in theory.
Working temperature: -20-60
Voltage: 12VDC5V, 12V, 18V, 24V optional (order specify the required voltage)
Output Channels:3 channels
Connection mode : Common Anode
Output current: Three-CMOS open-drain output
External dimension: L95 W52 H30mm
Packing size: L160 W95 H51mm
Static power consumption: <1W
output current: <4A (each channel)
output power: 5V: <60W, 12V: <144W, 24V: <288W
Adopt tow-sheath wire as power input interface,remarks: brown + blue
The input/output interface of signal:
Adopt four-sheath wires, remarks: black wire + brown wire R yellow wire
According to the screen prompts of RGB amplifier on the panel, connect the in/out signal wire by order, ensure short circuit can not occur between wire. then connect power wire for RGB amplifier. The specific description about the matching use of RGB Amplifier and LED,please refer to the following: typical application.
Supply voltage of this product is DC12V never connect to DC24V or AC220V directly
Never connect two wires directly in case of short circuit
Lead wire should be connected correctly according to colors that connecting diagram
* Warranty of this product is one year, in this period we guarantee replacement or repairing with no charge, but exclude the artificial situation of damage.
