12" w 24" l kent kgs-63-sd surface grinder, programmabl
12" W 24" L Kent KGS-63-SD SURFACE GRINDER, programmabl
12" Width 24" Length Kent KGS-63-SD SURFACE GRINDER, programmable auto idf, 3x auto feeds, emc, cool
12" x 24" Kent Hydraulic Surface Grinder
w/Electronic Programmable Automatic Incremental Downfeed
Model: KGS-63SD1 S/N: 98036404 New: 1998
Overall table working area ................. 11.81" x 25.59"
Longitudinal table travel:..................... 27.95"
Cross table travel:............................ 13.39"
Maximum table load (with chuck)................ 550 Lbs.
Maximum/Minimum distance betweek working
table and spindle center:.................... 21.25"/4.72"
Longitudinal table speed:................... 8 to 100 F.P.M.
Cross feed handwheel is graduated in
increments of:............................... .0001"
Automatic cross feed per stroke of table:...... .02" to .4"
Standard wheel dimensions:..................... 14" diameter
Spindle Speed:................................. 1,740 R.P.M.
Automatic down feed increment:............. 0.0001" to .004"
Downfeed handwheel is graduated in increments
of:.......................................... .0001"
Downfeed traver per revolution of handwheel:... .02"
Approximate Weight: .............................4,000 Lbs.
Electromechanically atuated cross feed
Automatic incremental downfeed of grinding wheelhead driven
Programmable logic controller (PLC) of all machine functions
"Rough Downfeed" increment and number of passes
"Fine Downfeed" increment and number of passes, "Sparkout"
times, "Downfeed Mode", for control of incremental
downfeed with table at right end of stroke, left end
of stroke, or both left and right end of stroke,
"Wheelhead Elevation & Position" for control of elevation
increment at completion of grinding job, "Jog" increment
to allow the operator to select three different jog rates
of the grinding wheelhead, and "reset" to set the current
position of the grinding wheel as 0 point. The PLC has a
LED Display to show the position of the grinding wheel in
relation to the starting point.
Selector switch for surface or plunge grinding modes of
Selector switch for automatic incremental downfeed, downward
jogging, or power rapid elevation of grinding wheelhead
12" x 23-5/8" Fine division electromagnetic chuck with
console mounted controls including ..... variable magnetic
strength, magnetization/demagnetization mode selector,
14" Diameter x 1.5" Width x 5" Bore Grinding Wheel
Over-The-Wheel parallel dresser
External coolant pump and tank with magnetic filtration
5 HP 3/60/230-460 volt spindle drive motor with electrical
