Ritter router R200T faceframe pocket hole borer machine
RITTER Router R200T Pocket Hole Machine
* air cylinder clamp and drive actuator
* 1.5 hp single phase 2xx volt motor
* needs very small compressed air supply
* ~384 lbs, 25 by 35 by 46 overall dimensions
See the following link for the factory information.
R200T Single Spindle Face Frame Pocket Borer
The image above shows the air clamp that secures the work.
The image below shows the spinning pocket hole bit below and away from the clamp.
The images above show the pocket hole bit comming in under the work clamp without and then with work in place.
The images below show the movement with the table removed.
The image seqence above shows a series of pocket holes getting routed.
The result is shown below (Looks like we could have used better wood & the bit needs shapening.
The placard is confusing. It says 115 volts but the motor says 2xx volts. ???
This Might Be Just What You Need For Your pocket hole router Application.
