50" tbl 3HP spdl majestic rm-1050-V3 vertical mill, acu
50" Tbl 3HP Spdl Majestic RM-1050-V3 VERTICAL MILL, Acu
50" Table 3HP Spindle Majestic RM-1050-V3 VERTICAL MILL, Acu-Rite Millpower CNC
Majestic CNC Knee Mill 10" x 50"
PRICE: $16,250 is for the 2 axis CNC - Call for pricing on
a 3rd Axis. The photo of this machine is shown with the
FOR A STREAMING VIDEO SHOWING THE FEATURES AND EASE OF USE
OF THE ACU-RITE MILLPWR CONTROL GO TO THIS WEB ADDRESS
http:// /index.cfm?PageID=8A4CC176-C09F-2715-7397FB20E4411134
Coolant Tank built in the base
3rd axis available (call for pricing)
Power Draw Bar available (call for pricing)
3 year manufacturers warranty on the glass scales, 2 year
mechanical machine limited warranty.
With the purchase of a new Acu-Rite Millpwr system, we will
give you 3 hours training on our floor for free.
over the phone and that is it. The Acu-Rite manual is
extremely clear and easy to follow. It covers most
Spindle Motor 3 HP,230/460V, 3 Phase
(Number of speeds) RPM (Variable) 70 - 3,800 RPM
Spindle Collet Capacity 1/8 to 7/8
Max. Spindle Center to Column 26
Head Movement 90 deg. R to L, 45 deg F to B
Maximum Workpiece weight 750 lbs
Overall Dimensions LxWxH 96 x 69 x 88
Note: Specifications are for your reference only. The
builder reserves the right to change or modify
specifications without prior notice. We reserve the right
to correct and not be held liable for any clerical errors.
STANDARD FEATURES AND ACCESSORIES:
Click Here For More Majestic Machines
