New 2†ashton air diaphragm pump (cast iron/buna-n)
This is a Brand New 2 Ashton Air Driven Double Diaphragm Pump.
Maximum Free Flow - Water: 568 lpm (150 US Gpm)
Inlet/Outlet Port Size/Standard: 2" Inch NPT/BSP Female
Maximum Air Consumption: 4.9 m3/min (175 scfm)
Maximum Partical Size: 6.3 mm (1/4 Inch)
Approximate Dissplacement/Stroke: 3.9 Litres (1.03 US Gallons)
Typical Sound Level at 4.9 Bar (70 Psi): 78 dBa
Weight - CAST IRON Construction: 28 Kg (62 lbs)
Weight - 304 & 316 St.St Construction: 59 Kg (130 lbs)
