6" w 18" l okamoto linear 6-18 surface grinder, roller
6" W 18" L Okamoto LINEAR 6-18 SURFACE GRINDER, ROLLER
6" Width 18" Length Okamoto LINEAR 6-18 SURFACE GRINDER, ROLLER BEARING TABLE, WALKER PMC,
6" X 18" OKAMOTO "LINEAR 618" "HIGH-PRECISION"
TABLE TO SPINDLE CENTER ........................... 18"
HEIGHT UNDER 8" WHEEL TO CHUCK SURFACE ............ 11"
LONGITUDINAL TABLE TRAVEL ......................... 19"
CROSS TRAVEL ....................................... 8"
CROSS FEED PER REV. OF HANDWHEEL
(.001" GRAD.) ................................... 0.100"
CROSS FEED HANDWHEEL VERNIER READS TO ........... 0.0001"
VERTICAL FEED PER REV. OF HANDWHEEL
(.0002" GRAD.) .................................. 0.0500"
APPROX. WEIGHT .................................. 2,020 LBS.
APPROX. DIMENSIONS ........................ 58" X 46" X 71"H
LONGITUDINAL TABLE TRAVEL ON LINEAR BALL BEARINGS DRIVEN
6" X 18" O.S. WALKER CERAMAX FINE-DIVISION PERMANENT
MANUALLY OPERATED ONE SHOT LUBRICATION SYSTEM
