Tektronix 2467B 400 mhz oscilloscope w/manuals
The Tektronix 2467B Oscilloscope, Analog: 400MHz,4ch (Stand alone) The Tektronix 2467B oscilloscope is a graph-displaying device it draws a graph of an electrical signal. In most applications, the graph shows how signals change over time: the vertical (Y) axis represents voltage and the horizontal (X) axis represents time. The intensity or brightness of the display is sometimes called the Z axis. The Tektronix 2467B oscilloscope's simple graph can tell you many things about a signal, such as: the time and voltage values of a signal, the frequency of an oscillating signal, the moving parts of a circuit represented by the signal, the frequency with which a particular portion of the signal is occurring relative to, other portions, whether or not a malfunctioning component is distorting the signal, how much of a signal is direct current (DC) or alternating current (AC) and how much of the signal is noise and whether the noise is changing with time.
SPECS: *** Bandwidth 400 MHz *** Rise time 875 ps *** Number of Channels 4 ch *** Min. Vertical Sensitivity 2 mV/div *** Maximum Vertical Sensitivity 5 V/div *** Vertical(or Deflection Factor) Accuracy 2 % *** Input Coupling AC,DC,GND *** Input Impedance 1 MOhm *** Input Impedance (alternate) 50 Ohm *** Maximum Input Voltage 400 V(dc+p *** Maximum Input#2 (for Impedance #2) 5 Vrms *** Main time base - lowest 5 ns/div *** Main time base - highest 500 ms/div *** B Sweep Time Base (low) 5 ns/div *** B Sweep Time Base (high) 50 ms/div *** Time base Magnification factor (X?) x10 *** Timebase accuracy 0.7 % *** Trigger Source External,Internal *** Trigger Sensitivity 0.35 mV
