Meriam multifunctionhart calibrator MFT4010-11-1-00 ce
MFT 4010 Multifunctional Modular Calibrator / HART Communicator
4010 Calibrator with HART Calibration and Configuration Functionality
-1 Standard Documenting (Interface to DMS Software for Calibration or HART Configuration Data)
-2 Adjustable Hanging/Shoulder Strap
-1 Standard 3-year DOF Download Subscription
The MFT 4010 is a break-through combination calibrator / HART communicator that truly reduces the time spent on field calibrations. The MFT 4010 Series delivers the versatility of a calibrator and the convenience of HART communications in one handheld unit.
Users can view up to four measurements simultaneously on the high resolution LCD or compare HART PV and AO values to corresponding values measured by the NIST traceable MFT. Available modules include differential, gauge, vacuum and absolute pressure as well as temperature and voltage/current. A voltage and current meter is integral to the base unit. All HART field devices can be configured, polled and trimmed using HART communications. Device Specific commands for supported devices are included with the MFT.
* All-In-One Tool takes the place of multiple handheld instruments,simplifies workload and improves productivity.
* Automation for HART field devices calibration is automated through auto setup of the calibrator based on the device settings; digital trims automatethe device adjustment steps.
* Calibration Types Supported pressure, t/c, RTD, I/P, P/I, Switch, Loopand mA/V for conventional HART transmitter or local indicators.
* Document As found and As left Calibration Results Create calibration procedures on the handheld or download them from compatible device management software. Save results to non-volatile memory.
* Field Updates uses Internet downloads to update and add capability /HART support.
* Modules select from a variety of positive-lock measurement modulesfor excellent versatility.
* Field Recertification sensor modules and integral V/I can be recalibratedfor zero, span and linearity via the MFT.
* User Interface 2.1 x 2.1 display, four soft keys (definitions change withmode requirements) and eight hard keys provide user interface. Display isconfigurable for 1 to 4 simultaneous measurements.
* User Convenience Auto shut off, Damping, Min/Max value capture, displayHold, sensor Zero, direct Contrast adjustment.
* Security Lockout Lockout specific MFT settings or all at one time. Diagnostics MFT 4010 self-tests upon power up and upon installation ofsensor modules. Advisories are posted on the display.
* Dedicated DOF Memory memory for 500 HART device drivers. Measurement Units customary English and Metric System units are selectable.
MFT 4010 Calibrator with HART CE
Base unit for modules and full Device Specific HART communications. Quick Cal displays HART PV and AO along
with MFT s NIST traceable measurements. User can identify needed trim(s) and access the trim function(s) from same display. Smart Trim allows selection of analog or digital trims without navigating through menu trees.
* HART lead kit with 250 ohm shunt adapter for HART communication (MFT 4010)
