Valby 50" log grapple & hyd rotator for custom install
Brand New GR50 Log Grapple with R45 Hydraulic Rotator Head.
* Maximum Gripping width is 50-3/4".
* Max Lift Capacity is 3080lb's.
* Height in the open position is 26-3/8".
* Height in the Closed Position is 19-1/2".
* Width of the widest Claw is 11".
* Working Pressure Rating is 2900psi.
* Jaw Steel thickness is .403".
* Jaw Material is Raex 640.
* Grapple weight is 209lb's.
* Maximum Load is 9900lb's!
* Max Working Pressure is 3000psi.
* Torque Rating is 737ft lb @ 2320psi.
* Pin Hole for attaching to Grapple Hanger is 1" Diameter.
