Sensormatic aps 100 electronic article surveillance
The following was taken from the manufacturers sales brochure:
The APS-100 system is an EAS detection system designed specifically for smaller retailers with single door exits. The system consists of a transmitting pedestal antenna and a receiving device. The transmitting pedestal contains the power/controller device, an audible alarm, and a visual alarm. The receiving device can be either a secondary pedestal or Ranger receivers. The APS-100 features plug-n-play installation, automatic adjustment to other Ultra Max systems in the area, and a warning light when tagged merchandise is positioned too close to the system.
Max. pedestal spacing Max. pedestal spacing
Automatic adjustment to the environment
Built-in audio and visual alarms
Primary input: 110-120Vac or 220-240Vac, 1A @ 50-60Hz
Primary power fuse: 1 A, 250V, slo-blow
Outputs: 1 Port for 1 antenna
Transmit burst duration: 1.6ms
Burst repetition rate (50Hz): 37.5Hz (normal), 75Hz (validation)
Burst repetition rate (60Hz): 45Hz (normal), 90Hz (validation)
Transmit coil resistance: 1.9 ohms
Alarm audio duration: 2 sec.
Audio decibel level: 80dB @ 1 meter
Inputs: 1 port for 1 antenna
Pedestal coil resistance: 3.16 ohms
Ranger coil resistance, inner: 0.1369 ohms, outer:
Operating temperature: 0 C to 50 C (32 F to 122 F)
Relative Humidity: 0 to 90% Non-Condensing
Emissions: 47 CFR, Part 15, EN300330, EN300683, RSS210
Safety: UL 60950, CSA C22.2 No. 60950, EN60950
Pedestal (HxWxD): 135 x 35 x 12.3 cm (53 x 13.8 x 4.75 in.)
Weight (Tx Ped): 10.9kg (24 lbs)
Weight (Rx Ped): 9.1 kg (20 lbs.)
Ranger Receiver (HxWxD) 24.1 x 3.5 x 8.6 cm (9.5 x
AMAX2-3: Pedestal with Rangers
ZSMAX2P: Transmitter pedestal only
ZSMAX2S: Receiving pedestal only
Multi Max system is a simplified version of the Ultra Post system. Multi Max is an economical solution for small-size shops trading clothing, cosmetics, and perfume, for drugstores preferring to employ acoustic-and-magnetic technology. The model combines reliable operation, high level of detection by sensors, attractive appearance, and reasonable price.
******** It is HIGHLY recommended that an ADT/Sensormatic Specialist install this system. It was working when I took it out of my store so there are no warranties. It must be installed correctly. ****************
