Index MS32 cnc automatic screw machine 6 spindle
6 Spindle CNC Automatic Screw Machine
Max. bar dia. with feed finger: 32 mm
Spindle pitch circle dia: 270 mm
Spindle carrier indexing: 0.95 sec
Power clamping by INDEX-spring loaded-hollow chucking cylinder and draw type collet
Hollow shaft A.C. motor with infinitely variable speed for each spindle
A.C. motor with infinitely variable speed
Rating at 25% duty cycle: 10 kW
Torque at 25% duty cycle: 16 Nm
Power clamping by three-jaw chuck
Hydraulic oil: H-LPD 32: 150 l
Floor space requirement of machine:3.7 m
