Cincinnati no. 2 tool & cutter grinder - model om
CINCINNATI No. 2 TOOL & CUTTER GRINDER - MODEL OM
SERVICE MANUAL & REPAIR PARTS CATALOG - 55 PAGES 1955
TO ADJUST WHEELHEAD DRIVE BELT . 13
" " WORKHEAD SPINDLE BEARINGS 14
CONVERSION CHART (INCHES INTO MILLIMETERS) 7
TO REMOVE ELEVATING WORM SHAFT . 17
" " SADDLE AND CROSS FEED SCREW NUT . 16
" " TABLE FEED PINION SHAFT ASSEMBLY . 16
" " WHEELHEAD COLUMN SLEEVE 16
" " REPLACE GRINDING WHEEL SPINDLE 15
LUBRICATION INSTRUCTIONS AND SPECIFICATIONS
ANGULAR WHEEL TRUING ATTACHMENT (Unit No. 1DBY) . 50-51
ATTACHMENTS (Unit No. 1DJF).. . 34-39
CYLINDRICAL GRINDING ATTACHMENT (Unit No. 1DBT)) . 50-51
FACE MILL GRINDING ATTACHMENT (Unit No. 1DCA). . 46-47
GEAR CUTTER GRINDING ATTACHMENT (Unit No. 1DBV) . 48-49
INTERNAL GRINDING ATTACHMENT (Unit No. I DBP) . 52-53
LONG REAMER GRINDING ATTACHMENT (Unit No. 1DBZ) . 44-45
MACHINE INSTRUCTION PLATES .54-55
MOTOR DRIVE (Unit No. 1DN) .32-33
RADIUS GRINDING ATTACHMENT No. 1 (Unit No. 1DGB) . 40-41
RADIUS GRINDING ATTACHMENT No. 2 (Unit No. 1DEJ). . 42-43
SADDLE TABLE (Unit No. 1DH) .22-27
SURFACE GRINDING ATTACHMENT (Unit No. 1DBU) . 48-49
WHEELHEAD (Unit No. 1DAW) .. 28-31
WORK BLADE GRINDING ATTACHMENT (Unit No. 1DBW 52-53
