Kepco ra 55 power supply mainframe w/ 6 modules
Kepco RA 55 Power Supply Mainframe w/ 6 Modules
Up for sale is a Kepco RA 55 Power Supply Mainframe with the following:
* (1) MST488-27 Controller Plug-In Module
* (5)MST 15-12M 01.15V 0-12A Plug-In Modules.
Kepco RA 55 accommodates nine (9) plug-in MST power supplies in a standard 19-inch wide rack mountable housing. Each power module can produce up to 200 watts, so that the total for the rack can be 1800 watts. RA 55's leftmost slot can be used to hold an interface, MST 488-27 that will allow the remaining eight (8) MST modules to be fully programmed via the IEEE 488.2 instrumentation bus. The rack has two a-c input connectors to allow the load to be distributed over two mains circuits. The a-c is distributed internally to the plug-in MST power supplies.
* Up to nine 200-watt power supplies in a 4U housing.
* Optional GPIB interface connects (8) eight MST modules to a single GPIB (IEEE 488.2) address with the capacity to control up to 19 additional power supplies.
* Switch-mode conversion, linear post regulator.
* Wide range a-c input: 88-264V a-c with built-in power factor correction (PFC).
* Forced current sharing for N+1 redundancy connection.
