> Tektronix s-6 S6 service manual
Tektronix s-6 S6 service manual
Reproduction quality very high-resolution scanned copy on CD-ROM
of the Instruction (service and operation) manual for the
plug-in for the 7000 series of oscilloscopes
This volume comprises 44-pages scanned from an original Tektronix manual to a file size of 28-MB Contains Operating Instruction, Service & Calibration info, parts lists, board photos, and complete schematic diagrams. No printing dates on this manual but it covers serial numbers B010100 through B030603 & above , with changes. Scanned from a like new manual this is truly a reproduction grade scan.
* Large fold out schematic pages are scanned FULL SIZE A3 11"X17"
