New 45 ton scotchman portafab ironworker, free shipping
45 Ton Punch Station (1-1/8" in 1/2")
2" Die Holder, Punch Nut with Wrench and Stripper
One Round Punch & Die: Max. Dia. 1"
Adjustable Electric Stroke Control with Scale
Three-In-One Combination Tool (take off $465 if eliminated)
3" x 3" x 5/16" at 90 and 2" x 2" x 1/4" at 45
Rod Shear Capacity: 3/4" Round
Machine Stand with Punch & Die & Tooling Storage Rack
All Guards Necessary to Comply with
Inexpensive and portable, this machine was designed with all types of
and small, and can also be taken on location to construction sites and
operated using a 110 volt generator.
Rated on: 65,000 PSI Tensile A 36 Mild Steel
Punching Capacity 45 Ton 1-1/8" in 1/2"
Special Tooling 2-1/4" Max. Dia.
Angle Shear 90 3" x 3" x 5/16"
Angle Shear 45 2" x 2" x 1/4"
Rectangle Notcher 2" x 1-3/4" x 1/4"
Square Tube Shear 1/2" to 1", 14 ga.
Picket Tool Housing 1/2", 3/4", 1"
Schedule 40 I.D. 3/4", 1", 1-1/4", 1-1/2", 2"
Strokes per minute in light material 1/4" Stroke 44 spm
Strokes per minute in heavy material 3/4" Stroke 14 spm
Motor Optional 2 hp 1 ph 220v (add $600 for 220v 1 Ph motor)
Dimensions W-17.63" x L-35.75" x H-38.75"
