> Maxim MAX1773 MAX1773A power selector ic 20PIN tssop
Maxim MAX1773 MAX1773A power selector ic 20PIN tssop
Brand New & Origianl Packing Maxim IC Chipsets
Model: MAX1773 / MAX1773A (Power Selector IC)
Power Source Selector for Dual-Battery Systems
Pin Package: 20pin TSSOP
Remark: 1. 2 chipsets at the same function & set.
The MAX1773/MAX1773A highly integrated ICs serve as the control logic for a system with multiple power sources. They directly drive external P-channel MOSFETs to select from an AC adapter and dual battery sources for charge and discharge. The selection is made based on the presence of the power sources and the state of the batteries. The MAX1773/MAX1773A detect low battery conditions using integrated analog comparators and check for the presence of a battery by using battery thermistor outputs.
The MAX1773/MAX1773A are designed for use with a buck topology charger. They provide a simple and easily controlled solution to a difficult analog power control problem. The MAX1773/MAX1773A provide most of the power source monitoring and selection, freeing the system power management microprocessor ( P) for other tasks. This not only simplifies development of the power management firmware for the P but also allows the P to enter standby, thereby reducing system power consumption.
* Patented 7-MOSFET Topology Offers Low-Cost Solution
* Automatically Detects and Responds to:
* Low Battery Voltage Condition
* Battery Insertion and Removal
* Direct Drive of P-Channel MOSFETs
* Simplifies Power Management P Firmware
* Extends Battery Life by Allowing Power Management P to Enter Standby
* 4.75V to 28V AC Adapter Input Voltage Range
* Integrated LDO with 1mA Drive Capability
* Small Footprint 20-Pin TSSOP Package
Dual-Battery Portable Equipment
Notebook and Subnotebook Computers
