Hp agilent E1600A multiport test module vxi
HP Agilent E1600A Multiport Test Module VXI
The Agilent E1600A Multiport UNI Signaling Performance Test Module generates real world signaling traffic at high rates and provides continuous real-time measurements across multiple ports.
Determine the signaling capabilities of an ATM switch or network, quickly, easily and reliably by equipping the Agilent Broadband Series Test System with this solution.
Simulate, in a controlled and deterministic fashion, real-world signaling conditions by specifying call attempt rate, call duration, source and destination addresses, and SETUP parameters.
An extensive set of measurements and events are provided to allow you to determine the performance of the system under test. All measurements are made in a continuous and real-time fashion to ensure that a reliable and accurate picture of the switch's ATM signaling performance can be made.
Configure up to 5 modules (20 ports) in a single integrated test system
Generate realistic SVC call generation profiles up to a total of 9,000,000 busy hour calls at 2,500 calls/s per system
Maintain up to 125,000 simultaneous active connections per system
Stress the Connection Admission Control function with high call volumes and control over traffic contract parameters
Measure time-correlated SVC call statistics on all ports simultaneously
Capture, decode and display interleaved, multiport signaling and ILMI PDU captures
Maximum active call capacity
Ratio of accepted, rejected, cleared and unreleased calls to outgoing call attempts
Ratio of received, accepted, rejected and cleared calls to incoming call attempts
Distribution of clearing causes for incoming and outgoing call attempts
Variation of SVC setup and teardown times versus call attempt rates and active call levels
User Programming Environment simplifies regression test development and ensures repeatability
Users can integrate their own scripts into test configurations
