Acrison stainless steel screw 8" auger feeder w hopper
Item FEEDER Manufacturer ACRISON Model 103B Material Stainless Steel Description Acrison stainless steel screw feeder. Model 103B-0000-600-800-BDF. Serial Number 84079-01. Feed screw is 8" in diameter and 112" long (36" of screw is pigtail design, remainder is solid screw) with 60" of tube that empties to a 12.5" discharge. Has twin conditioning augers that are 19" in diameter and 48" long. Hopper is 48" w x 48" l at bottom and 67"w x 72" at top. The entire hopper 78" tall with 12" diameter infeed. Main screw is driven by 5 hp 180 vdc motor. Each of the conditioner screws are driven by a 3 hp 480 vac motor. Requires 480 vac 3ph electrical power.
