Pantographic tapping arm M5 to M16 1000MM work area
The ARM-1000-16 tapping arm is capable of tapping between M5 and M16 threads within a 1000mm work area...
The machine taps are held in a quick change collet system driven by a pneumatic motor. The motor is mounted on a articulated arm which maintains parallel motion. The smooth arm action allows the tap to be brought into position swiftly and easily.
The tap collets have a ratchet clutch, the torque is preset for each tap size. If the tap encounters an obstruction the clutch will prevent the tap from turning. Through hole and blind holes can be tapped.
With the increase in speed over hand tapping and removing tapping operations from manual and cnc machinery, our tapping arm will prove to be an affordable alternative.
* Removes tapping operations from machine tools.
* Easy to re-align with threaded holes to remove contamination after painting or coating processes.
* Blind and through hole tapping.
Included With Arm: Pantographic Arm, Reversible pneumatic motor, Quick change chuck (Collets supplied separately) , Air regulator, pressure gauge, filter and lubricator.
TA-1000-16 Tapping Arm - Technical Information.html
