76" tbl 10HP spdl kearney&trecker 410-S15 vertical mill
76" Tbl 10HP Spdl Kearney&Trecker 410-S15 VERTICAL MILL
76" Table 10HP Spindle Kearney&Trecker 410-S15 VERTICAL MILL, #50 Taper, Geared Head, Box Ways,
MODEL: 410-S-15, S/N: 4-9649, MFG: 1965
TABLE SIZE .................................. 76" X 15"
LONGITUDINAL TABLE TRAVEL ......................... 42"
CROSS TABLE TRAVEL ................................ 14"
VERTICAL TABLE TRAVEL ............................. 14"
HEAD VERTICAL TRAVEL ............................... 6"
FEED RANGE LONGITUDINAL & CROSS .......... 1/2 - 64 IPM
FEED RANGE VERTICAL ...................... 1/4 - 32 IPM
RAPID TRAVERSE LONG. & CROSS .................. 150 IPM
RAPID TRAVERSE VERTICAL ........................ 75 IPM
SPINDLE TAPER ................................. #50 STD
SPINDLE SPEEDS (24) ..................... 25 - 2000 RPM
NET WEIGHT .................................. 9,500 LBS
APPROXIMATE SIZE ...................... 51" X 92" X 94"
RAPID TRAVERSE & FEEDS ALL DIRECTIONS
10 HORSE POWER SPINDLE DRIVE MOTOR
