400 ton williams & white down acting hydraulic press
ONE Preowned WILLIAMS & WHITE Down Acting Hydraulic Press
Mdl. SH400-144-60, S/N C-4192, NEW 1976
PRESSING CAPACITY 400 TON
STRIPPING CAPACITY ... 120 TON
LIFTING CAPACITY @ RAPID RETURN SPEED ... 15 TON
AREA OF PLATENS .. 144 R-L X 60 F-B
AREA OF STEAM PLATENS 144 X 60 X 3
DISTANCE BETWEEN HOUSINGS 146 R-L
DAYLIGHT BETWEEN STEAM PLATEN FACES . 48
STROKE 33
SHUT HEIGHT . 15
MAIN RAM DIAMETER .. 16 X 13-1/4
NUMBER OF MAIN RAMS . 1
KICKER RAM DIAMETER .. 7-1/2 X 6-1/4
NUMBER OF KICKER RAMS 2
RAPID TRAVERSE DOWN 41 - 408
FULL PRESSURE, ADJUSTABLE 2 - 35
SLOW RETURN STRIPPING, ADJUSTABLE 5 - 114
RAPID TRAVERSE UP .. 38 - 380
MAXIMUM HYDRAULIC PRESSURE . 2764 PSI
HYDRAULIC PUMP OILGEAR .. DV-6025-V
MAIN MOTOR .. 75 HP
PRICE: ON SITE, PONTIAC, MI .. . $85,000.00
