Rf bnc female connector panel crimp for RG174,RG316
RF BNC female connector panel crimp for RG174,RG316
Temp.range................-65 +165 (PE Cable )centigrade
Vibration.................MIL-STD-202,Method 213
Impedanec.................50 .75
Frequency Range...........DC 4GHz
Working Voltage...........500V max
Withstand Voltage.........1500V rms
Center Contact............ 1.5m
Outer Contact............. 1m
Insulation resistance .... 5000 m
VSWR Straight............. 1.22
Right angle?.............. 1.30
Durability(mating)........ 500 (cycles)
shell ..............brass ................nickelplated
contact pin ........brass.................gold or silverplated
socket............. beryllium.............gold or silverplated
elastic contact.... beryllium ............gold or silverplated
crimping suite..... copper alloy......... nickelplated
0-ring sealing .....6146 silastic
