Hubbell WS12771 passive infrared wall switch (ivory)
Passive Infrared Wall Switch (Ivory)
$62.36 (Amazon.com) $102.60 (DrillSpot.com)
Hubbell WS1277 Passive Infrared Wall Switch:
WhiteHubbell s Wiring Devices division offers a wide array of electrical and electronic wiring devices, wire management systems, occupancy sensors, lighting controls and specialized wiring products for the marine and healthcare markets.
Hubbell WS1277 series wall switch sensors include a manual adjustment that allows the time delay to be set from 3 to 30 minutes.
This adjustment is concealed behind the front cover to prevent tampering.
These sensors also feature a push button ambient light level control that allows for quick, accurate setting of the ambient light level threshold.
Hubbell WS1277W Passive Infrared Wall Switch, White
Product Type: Wall-switches; Voltage: 120/277V AC, 50/60 Hz
Sensing Technology: Passive Infrared
Power Supply/Requirements: 120/277V AC, 60 Hz
Load Capacity: 120V AC- 0 to 800 Watts, 277V AC- 0 to 1200 Watts
Agency Approvals: UL Listed, cUL Certified
Housing: Flame Retardant UL 94 V-0 ABS
Dimensions: Face: 2.61"H x 1.29"W, .73"D (from wall out)
Mounting Height: 42 to 54 inches above floor
Operating Temperatures: 32 F to 122 F (0 C to 50 C) with rate of change not exceeding 20 F (11 C) per hour; 20% to 90% non-condensing relative humidity
Storage Temperatures: -40 F to 150 F (-40 C to 65 C); 20% to 90% non-condensing relative humidity.
Time Delay: Manual 20 seconds to 30 minutes
Ambient Light: Digital Pushbutton, 30 to 300 foot candles
Front Press Switch: Auto/Momentary Off (30 minutes after last motion, switch returns to automatic mode)
Service Switch: Auto/Off; Passive Infrared Sensing
