Hp 54520A 54522A 54540A & 54542A manual set (5 volumes)
Everything you ever wanted to know about your Hewlett Packard 54520A, 54522A, 54540A, AND 54542A Oscilloscope.
1) QUICK START GUIDE . Part # 54542-97002, 19-pages, 9-MB : Covers basic start up and front panel control usage.
2) USERS REFERNCE , part # 54542-97049, 300-pages, 83-MB: Covers detailed operating instructions and menu functions,
3) PROGRAMMER S REFERNCE , part# 54542-97038, 565-pages, 23-MB : The title says it all! 565 pages of comprehensive programming information for this highly flexible piece of equipment.
4) SERVICE GUIDE , part # 54542-97045, 128-pages, 26-MB: Covers basic setup and operation, performance tests, adjustment and calibration, extensive troubleshooting guides and menu use, FRU (field replaceable units and parts), and theory of operations. There are NO DETAILED SCHEMATICS ( HP did not publish schematics for any of the 54XXX series of scopes).
5) FEELING COMFORTABLE WITH DIGITIZING OSCILLOSCOPES-GUIDE TO TECHNOLOGY , part # 9320-5776, 39-pages, 27-MB: A useful comparison of the basic operational differences between traditional analog oscilloscopes and the newer digitizing oscilloscopes.
All four manuals are fully book-marked and the electronic page numbers match the original manual numbers (2-1, 2-2, 2-3 etc).
The service manual includes information on calibration, replaceable parts and extensive trouble shooting information including step-by-step decision tree failure isolation guides .
