6 taper 24.375" dia. wohlhaupter UPA5-S6 boring head
6 TAPER 24.375" DIA. Wohlhaupter UPA5-S6 BORING HEAD
WOLHAUPTER BORING AND FACING HEAD
TAPER OF SHANK ..................... #6 MT
MAXIMUM FACING AND BORING RANGE .... 24.375"
STROKE OF SLIDE .................... 2.05"
SELFACTING SLIDE FEED RANGE(12) ... .0008 TO .0096 I.P.R.
MAXIMUM SPEED ...................... 700 R.P.M.
MAXIMUM RECOMMENDED H.P. ........... 9.4 H.P.
APPROXIMATE WEIGHT: ................ 35 LBS.
ORIGINAL WOOD BOX WITH BORING BARS AND HOLDERS, ETC. AS
SHOWN IN ACTUAL PHOTOS - LOOKS LIKE CLOSE TO THE COMPLETE
SET ORIGINALLY PROVIDED WITH THE UNIT.
