4' arm 9" col dia cincinnati-bickford radial drill
4' Arm 9" Col Dia Cincinnati-Bickford RADIAL DRILL
4' Arm Lth 9" Col Dia Cincinnati-Bickford RADIAL DRILL
4 X 9 CINCINNATI-BICKFORD RADIAL DRILL
ARM LENGTH ...................... 4
COLUMN DIAMETER ................. 9
TAPER IN SPINDLE ................ NO. 4 M.T.
VERTICAL SPINDLE TRAVEL ......... 10
MAX. DISTANCE, SPINDLE TO BASE .. 53
MIN. DISTANCE, SPINDLE TO BASE .. 15
WORKING SURFACE OF MAIN BASE .... 30 X 53
HEIGHT OF BASE .................. 6
9 SPINDLE SPEEDS ................ 60-1200 RPM
MAX. HEIGHT OVER HEAD ........... 95
APPROX. WEIGHT .................. 5,500 LBS.
- 18 X 24 X 20 H T-SLOTTED BOX TABLE
- 3 HP 3/60/220-440 VOLT MOTOR
