42" tbl 2HP spdl siber hegner rb-i bed type vertical mi
42" Tbl 2HP Spdl Siber Hegner RB-I Bed Type VERTICAL MI
42" Table 2HP Spindle Siber Hegner RB-I Bed Type VERTICAL MILL, Bed Mill,Vari-Speed,Kurt PDB, Anilam
SIBER HEGNER VERTICAL BED TYPE MILL
MODEL: RB-1, S/N: 77010446, NEW: 1988
TABLE WORKING SURFACE .............. 9" x 42"
SPINDLE SPEED (LOW RANGE) ......... 60 - 580 RPM
SPINDLE SPEED (HIGH RANGE) ........ 500 - 4500 RPM
SPINDLE TAPER ..................... R-8
SPINDLE QUILL TRAVEL .............. 5"
TABLE LONGITUDINAL (X) ............ 30"
CROSS (Y) ......................... 12"
VERTICAL HEAD (Z) ................. 16"
SPINDLE HEAD THROAT DIMENSIONS:
SPINDLE NOSE TO TABLE SURFACE ..... 2"MIN - 20"MAX
SPINDLE CENTER TO COLUMN .......... 16"
HEAD TILTS ........................ 45% LEFT or 45% RIGHT
APPROX MACHINE WEIGHT .............. 2,270 LBS
APPROX FLOOR SPACE ................. 82"W x 50"D x 87"H
ANILAM TWO AXIS DIGITAL READOUT
